No. Item Q'ty
- Allen key 1
*1
An Allen key is provided for the hex bolts. One lock washer is provided for each socket bolt.
• Be sure to attach one lock washer to each hex socket bolt before you fasten the bolt.
1. Locate the vertical positioning pins at the top of both sides of the assembled scanner
stand.
2. Remove the orange tape [A], [B] from both ends of the scanner unit.
Main Machine Installation
79
