Ricoh MP CW2201 Service Manual

SP5-816-208 Error Codes
Cause Code Meaning Solution/ Workaround
Operation Error,
Incorrect Setting
-12002
Inquiry, registration attempted
without acquiring Request No.
Obtain a Request Number
before attempting the Inquiry or
Registration.
-12003 Attempted registration without
execution of a confirmation and no
previous registration.
Perform Confirmation before
attempting the Registration.
-12004 Attempted setting with illegal entries
for certification and ID2.
Check ID2 of the mainframe.
-12005 @Remote communication is
prohibited. The device has an
Embedded RC gate-related
problem.
Make sure that "Remote
Service" in User Tools is set to
"Do not prohibit".
-12006 A confirmation request was made
after the confirmation had been
already completed.
Execute registration.
-12007 The request number used at
registration was different from the
one used at confirmation.
Check Request No.
-12008
Update certification failed because
mainframe was in use.
Check the mainframe
condition. If the mainframe is in
use, try again later.
-12009 The ID2 in the NVRAM does not
match the ID2 in the individual
certification.
Check ID2 of the mainframe.
-12010 The certification area is not
initialized.
Initialize the certification area.
2. Installation
188

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
