Ricoh MP CW2201

3. Raise the top of scanner unit to the full upright position (p.254).
4. Remove the original table (p.261).
5. Remove the sensor cover. ( x2)
6. Remove the screws of the sensor bracket and turn the bracket over. ( x3)
4. Replacement and Adjustment
286
