Ricoh MP CW2201 Service Manual

11. From the right of the roll unit 1, remove the upper [A] and lower screws [B] ( x2).
12. On the front of the main unit, raise the paper exit guide [A] and push the harness of the
roll unit 1 [B] to the front over the top of the roll unit 1.
13. From the front of the machine, push the roll unit 1 slightly to the left [1], and then remove
it [2].
Roll Units
319
