Ricoh MP CW2201 Service Manual

2. Remove the cover the feed roller housing ( x3).
• Slide the feed roller housing and cover plate in the opposite direction to free the bosses from
their notches, and then separate them.
You can see the feed roller [A].
4. Replacement and Adjustment
356

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
