• Do not place any film under the carriage unit.
• To place the plain paper, do not pull up the paper holding lever too much (p.226).
2. Remove the top cover (p.245).
3. Remove the head lift motor [A]. ( x1, x3)
Head Lift Motor
4. Replacement and Adjustment
424
