Ricoh MP CW2201 Service Manual

• The black print heads have two main ink level sensor feelers [A], and the color print heads have
five [B].
1. Remove the carriage unit covers (p.427).
2. Remove the thermistor from the head tank (K2) of the print head unit.
• Unbend the tip of the harness then remove.
4. Replacement and Adjustment
430

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
