6. Release the FFCs (front side) from the bottom of the HRB. ( x3)
• To release the FFCs, be sure you understand of the directions of the locks.
• To release the FFCs [A], pull the lock toward you.
• To release the FFCs [B], push up the lock.
Carriage Unit
449

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
