Ricoh MP CW2201 Service Manual

SP4-965 Problem Effect
1 Leading edge The original feeding is interrupted at the position
where the original is fed by the distance of the original
exit roller (112.2 mm) from where the original
registration sensor detects the leading edge of the
original. Then the scan speed is lowered by the set
value.
2 Position To adjust the starting position of SP4-965-001 (Scan
Speed Adjustment: Leading Edge).
3 Trailing edge The scan speed is changed to the value set for
SP4-965 14.5 mm after the original set sensor detects
the original trailing edge.
2. Enter the value and touch [Set].
3. Touch [Exit] once.
4. Repeat steps 1 to 3.
Special Adjustments
589

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
