SC202 D Ink Level Detection Feeler Position Error
One of the following conditions existed:
• When air was purged one or more of the feelers could not be detected
so the operation could not continue.
• When the maintenance pump attempted to apply negative pressure on
the print head ink tank, the feeler could not be detected at its prescribed
position after the pressure was applied.
• OCFS could not detect the feeler(s) after the feeler sensor performed the
check after filling.
SC202-00 D Full Tank Detection Feeler Position Error
Interrupted during specifying the cause
SC202-01 D Head Tank 1: Ink Level Sensor Feeler Error at Air Release
SC202-02 D Head Tank 2: Ink Level Sensor Feeler Error at Air Release
SC202-03 D Head Tank 3: Ink Level Sensor Feeler Error at Air Release
SC202-04 D Head Tank 4: Ink Level Sensor Feeler Error at Air Release
SC202-05 D Head Tank 5: Ink Level Sensor Feeler Error at Air Release
SC202-06 D Head Tank 6: Ink Level Sensor Feeler Error at Air Release
SC202-07 D Head Tank 7: Ink Level Sensor Feeler Error at Air Release
Feeler cannot be detected during air release.
• Feeler cannot be detected because it is out of position (loose, broken,
defective, or blocked by an obstruction)
• Air release solenoid blocked
• Maintenance unit defective
• Print head ink tank defective
• Air release solenoid defective
SC202-11 D Head Tank 1: Air Leak at Negative Pressure
SC202-12 D Head Tank 2: Air Leak at Negative Pressure
SC202-13 D Head Tank 3: Air Leak at Negative Pressure
SC202-14 D Head Tank 4: Air Leak at Negative Pressure
6. Troubleshooting
662
SC202 at installation
RTB 41
