Ricoh MP CW2201 Service Manual

No. Component Function
15 Air Sensor: K1 Detects excess air in the K1 ink sub tank of the K1 print head
unit.
16 OCFS 7 (Y2) On Carriage Filler Sensor Y2. The on-carriage sensor that
monitors the position of the feeler arm on the side of the Y2 ink
sub tank. The movement of this sensor is used to signal low ink
in the Y2 sub tank.
17 OCFS 6 (M2) On Carriage Filler Sensor M2. The on-carriage sensor that
monitors the position of the feeler arm on the side of the M2 ink
sub tank. The movement of this sensor is used to signal low ink
in the M2 sub tank.
18 OCFS 5 (C) On Carriage Filler Sensor C. The on-carriage sensor that
monitors the position of the feeler arm on the side of the C ink
sub tank. The movement of this sensor is used to signal low ink
in the C sub tank.
19 OCFS 4 (M1) On Carriage Filler Sensor M1. The on-carriage sensor that
monitors the position of the feeler arm on the side of the M1 ink
sub tank. The movement of this sensor is used to signal low ink
in the M1 sub tank.
20 OCFS 7 (Y1) On Carriage Filler Sensor Y1. The on-carriage sensor that
monitors the position of the feeler arm on the side of the Y1 ink
sub tank. The movement of this sensor is used to signal low ink
in the Y1 sub tank.
21 OCFS 2 (K2) On Carriage Filler Sensor K2 The on-carriage sensor that
monitors the position of the feeler arm on the side of the K2 ink
sub tank. The movement of this sensor is used to signal low ink
in the K2 sub tank.
Electrical Components
753

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
