No. Component Function
4 PSU Power Supply Unit. Connected to the external power source,
provides DC current that runs the machine and all its
components.
5 IOB Input/Output Board. This functions as the interface for data
transmission and power supply to the paper supply module
and scanner module.
This controls the driver for paper supply, head up/down,
maintenance motor, ink supply, and ink drop detection.
- RFDB Roll Feed Drive Board. Controls the operation of Roll Unit 2.
Provided with Roll Unit 2 (option).
- MLB Media Link Board (File Format Converter). An option.
Documents saved with the copy/printer function can be
received from your client computer via a network, using Desk
Top Binder, for example.
6. Troubleshooting
758
