Ricoh MP CW2201 Service Manual

2-902 Internal Test Pattern Select - RI20 (MtoP) Internal Patterns
Pattern
0 No Test Pattern Output
1 Black Grid Pattern
2 Cyan Grid Pattern
3 Magenta Grid Pattern
4 Yellow Grid Pattern
5 Frame Pattern
6 Black 2x2 Pattern
7 Cyan 2x2 Pattern
8 Magenta 2x2 Pattern
9 Yellow 2x2 Pattern
10 Density Pattern 1
11 Density Pattern 2
IPU Test Patterns
4-417 IPU Test Pattern Setting - Pattern Selection
No. Pattern Name
0 Scanned Image
1 Gradation Main Scan A
2 Color Patch 16
3 Grid Pattern A
4 Slant Grid Pattern B
5 Slant Grid Pattern C
6 Slant Grid Pattern D
7 Scanned + Grid Pattern C
Image Processing
795
