Ricoh MP CW2201 Service Manual

North America 120-127V 15A 60 Hz
Europe/Asia/China 220-240V 8A 50/60 Hz
Power Consumption Ave. Less than 100W
Max. Less than 180W
Sleep Mode Less than 1.1W
Low Power Mode Less than 80W EU, Asia, China
Less than 70W NA
Dimensions (w x d x h) 1384 x 1022 x 1214 mm
(54.5 x 40.2 x 48 in.)
Weight Less than 120 kg (264 lb.)
Environment
Sound Power Level Standby 40 dB or less
Copying B&W 68 dB or less
FC 66 dB or less
Sound Pressure Level Standby 36 dB or less
Copying B&W 60 dB or less
FC 60 dB or less
Ozone Emission None
Printer Specifications
Ink Pigment based YMCK
Interface
Standard Ethernet(1000BASE-T/100BASE-TX/10BASE-T),USB2.0,SD card
slot
Options Wireless LAN (IEEE802.11a/b/g/n*
1
), Gigabit Ethernet
1. Specifications
8

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
