Main SP Tables-4
SP4-XXX
4008 Scanner Sub Scan - Magnification Adjustment
[-0.9 to 0.9/0.0/0.1%]
4010 Scanner Sub Scan
1 Leading Edge Registration Adjustment
[-10 to 10/0.0/ 0.1 mm]
• A higher setting "+" shifts the image down (against the sub scan direction).
• A lower setting "-" shifts the image up (with the sub scan direction).
2 Trailing Edge Registration Adjustment
[-10 to 10/0/0.1 mm]
• A higher setting "+" shifts the image down (against the sub scan direction).
• A lower setting "-" shifts the image up with the sub scan direction).
4011 Scanner Main Scan - Registration Adjustment
[-4 to 4/0.0/0.1 mm]
• A higher setting "+" shifts the image away from the right edge of the paper as it
exits for a wider margin.
• A lower setting "-" shifts the image to toward the right edge of the paper as it exits
for a narrower margin.
4012 Scanner Edge Margin
5 DF: Leading Edge
[0 to 9/0.0/0.1 mm]
6 DF: Trailing Edge
[0 to 9/0.0/0.1 mm]
3. SP Mode Tables
74
