4417 IPU Test Pattern Setting - Pattern Selection
[0 to 8/0/1]
No. Pattern Name
*0 Scanned Image
1 Gradation Main Scan A
2 Color Patch 16
3 Grid Pattern A
4 Slant Grid Pattern B
5 Slant Grid Pattern C
6 Slant Grid Pattern D
7 Scanned + Grid Pattern C
8 Scanned + Grid Pattern D
4606 White Level Adjust
1 Gain Adjustment [0 to 1023 / 860 / 1 digit]
2 LED Adjustment [0 to 1023 / 800 / 1 digit]
3 LED Adjustment(Gain Default) [0 to 1023 / 450 / 1 digit]
4700 FPGA ID Indication – Volans
4709 Gray Balance Adj Value: Current
[-1024 to 1023/0/1]
• Display format: Hexadecimal
• The values are stored after the machine is cycled off/on.
• The settings are stored in the RI2005-SIB register
1 to 3 CIS1: G, R, B
4 to 6 CIS2: G, R, B
7 to 9 CIS2: G, R, B
3. SP Mode Tables
76
