20．PROFINET COMMUNICATION

(10) Motion profile type (P24710)

Set the acceleration/deceleration pattern in the profile position mode (pp). The description is as follows.

PNU

Sub

Access

Name

Data Type

Description

Default

24710

R/W

Motion profile type

Integer16

Acceleration/deceleration pattern

generation

-1

PNU

Sub

Range

Units

EEP-ROM

Parameter

24710

FFFFh to FFFFh

Impossible

Acceleration/deceleration type selection

Setting

value

Description

-1

S-pattern

Linear ramp (not compatible) (Note)

Sin

ramp (not compatible) (Note)

Jerk-free ramp (not compatible) (Note)

Jerk-limited ramp (not compatible) (Note)

Note.

This is not supported by the driver.
