APPENDIX
App. - 20
Setting
value
Output item
Description
Setting
value
Output item
Description
0D
Bus voltage (Note 4)
400 [V]
0
8 [V]
0E
Speed command 2
(Note 3)
Maximum speed
CW direction
CCW direction
Maximum speed
0
8 [V]
-8 [V]
10
Load-side droop pulses
(Note 3, 5, 6)
(±10 V/100 pulses)
100 [pulse]
CW direction
CCW direction
100 [pulse]
0
10 [V]
-10 [V]
11
Load-side droop pulses
(Note 3, 5, 6)
(±10 V/1000 pulses)
1000 [pulse]
CW direction
CCW direction
1000 [pulse]
0
10 [V]
-10 [V]
12
Load-side droop pulses
(Note 3, 5, 6)
(±10 V/10000 pulses)
10000 [pulse]
CW direction
CCW direction
10000 [pulse]
0
10 [V]
-10 [V]
13
Load-side droop pulses
(Note 3, 5, 6)
(±10 V/100000 pulses)
100000 [pulse]
CW direction
CCW direction
100000 [pulse]
0
10 [V]
-10 [V]
14
Load-side droop pulses
(Note 3, 5, 6)
(±10 V/1 Mpulses)
1 [Mpulse]
CW direction
CCW direction
1 [Mpulse]
0
10 [V]
-10 [V]
15
Motor-side/load-side
position deviation
(Note 3, 5, 6)
(±10 V/100000 pulses)
100000 [pulse]
CW direction
CCW direction
100000 [pulse]
0
10 [V]
-10 [V]
16
Servo motor-side/load-
side speed deviation
Maximum speed
CW direction
CCW direction
Maximum speed
0
8 [V]
-8 [V]
17
Internal temperature of
encoder (±10 V/
±128 °C)
128 [°C]
-128 [°C]
0
10 [V]
-10 [V]
Note 1.
Encoder pulse unit.
2.
Available in position mode
3.
This cannot be used in the torque mode.
5.
This cannot be used in the velocity mode.
7.
For details on the value of the maximum current command (maximum torque) for ±8 V, refer to app. 7.3.
