SMC Networks LECSN-T Series User Manual

5. PARAMETERS
5 - 28
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Network
ECT
EIP
PNT
PA15
*ENR
Encoder
output pulses
Set the encoder output pulses from the driver by using the number of output pulses
per revolution, dividing ratio, or electronic gear ratio. (after multiplication by 4)
Selecting "Dividing ratio setting (_ _ 1 _)" of "Encoder output pulse setting selection"
in [Pr. PC03] will divide the travel distance [pulse] of the linear encoder by the
setting value.
Set a numerator of the electronic gear for the A/B-phase pulse output when
selecting "A-phase/B-phase pulse electronic gear setting (_ _ 3 _)" of "Encoder
output pulse setting selection" in [Pr. PC03].
Refer to app. 12 for details.
The maximum output frequency is 4.6 Mpulses/s. Set the parameter within this
range.
Setting range: 1 to 4194304
4000
[pulse/
rev]
PA16
*ENR2
Encoder
output pulses
2
Set a denominator of the electronic gear for the A/B-phase pulse output.
Set a denominator of the electronic gear when selecting "A-phase/B-phase pulse
electronic gear setting (_ _ 3 _)" of "Encoder output pulse setting selection" in [Pr.
PC03].
Selecting "Dividing ratio setting (_ _ 1 _)" of "Encoder output pulse setting selection"
in [Pr. PC03] will disable the setting value.
Refer to app. 11 for details.
The maximum output frequency is 4.6 Mpulses/s. Set the parameter within this
range.
Setting range: 1 to 4194304
1
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Network
ECT
EIP
PNT
PA17
**MSR
Servo motor
series setting
Do not change this value.
0000h
PA18
**MTY
Servo motor
type setting
Do not change this value.
0000h
