5. PARAMETERS
5 - 70
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Network
ECT
EIP
PNT
PE35
**FBD2
Fully closed
loop control -
Feedback
pulse
electronic
gear 2 -
Denominator
Do not change this value.
1
PE41
EOP3
Function
selection E-3
_ _ _ x
Robust filter selection
0: Disabled
1: Enabled
When "Enabled" is set, the machine resonance suppression filter 5 that is set in [Pr.
PB51] is not available.
0h
_ _ x _
For manufacturer setting
0h
_ x _ _
0h
x _ _ _
0h
PE44
LMCP
Lost motion
compensatio
n positive-
side
compensatio
n value
selection
Set the lost motion compensation for when reverse rotation (CW) switches to
forward rotation (CCW) in increments of 0.01% assuming the rated torque as 100%.
Setting range: 0 to 30000
0
[0.01%]
PE45
LMCN
Lost motion
compensatio
n negative-
side
compensatio
n value
selection
Set the lost motion compensation for when forward rotation (CCW) switches to
reverse rotation (CW) in increments of 0.01% assuming the rated torque as 100%.
Setting range: 0 to 30000
0
[0.01%]
PE46
LMFLT
Lost motion
filter setting
Set the time constant of the lost motion compensation filter in increments of 0.1 ms.
If the time constant is "0", the torque is compensated with the value set in [Pr.
PE44] and [Pr. PE45]. If the time constant is other than "0", the torque is
compensated with the high-pass filter output value of the set time constant, and the
lost motion compensation will continue.
Setting range: 0 to 30000
0
[0.1 ms]
