PT71
DCTH
Travel
distance after
proximity dog
(extension
parameter)
This parameter is the extension parameter of [Pr. PT09].
When [Pr. PT71] is used, the travel distance after proximity dog is calculated as
follows.
Travel distance after proximity dog = [Pr. PT09] + ([Pr. PT71] × 65536)
This function will be enabled in the profile mode and cyclic synchronous mode.
The unit can be changed to 10
STM
[μm], 10
(STM-4)
[inch], 10
-3
[degree] or [pulse]
according to the setting of [Pr. PT01].
Setting range: 0 to 32767
0
Refer
to
Function
column
for unit.
PT72
ECMXL
Synchronous
encoder
electronic
gear -
Numerator
(lower four
digits)
Set an electronic gear numerator for converting a synchronous encoder command
into a command unit. Upper and lower are a set.
Set the electronic gear in hexadecimal.
Setting value of this parameter:
[Pr. PT72]
[Pr. PT73]
Upper four
digits
Lower four
digits
Set a value within the following range. When a value outside the range is set,
synchronous control error will occur and synchronous control will not start even
though Synchronous control command (Control DI7 bit 12) is input.
Setting "0" will apply "1".
1
16000
Synchronous encoder electronic gear - Numerator
Synchronous encoder electronic gear - Denominator
< < 6000
To enable the parameter value, cycle the power or turn on Analysis command
(Control DI 7 bit 14).
This parameter corresponds to "External encoder gear numerator (Class ID: 64h,
Ins ID: 2DF0h, Attr ID: 1)". When this parameter is mapped for the I/O
communication, the value written with Setup software (MR Configurator2
TM
) is
overwritten with the upper side. Thus, do not write a value with Setup software (MR
Configurator2
TM
).
Setting range: 00000000h to FFFFFFFFh
PT73
ECMXH
Synchronous
encoder
electronic
gear -
Numerator
(upper four
digits)
Set an electronic gear numerator for converting a synchronous encoder command
into a command unit. Upper and lower are a set.
Refer to [Pr. PT72] for details.
