5. PARAMETERS
5 - 98
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Network
ECT
EIP
PNT
PT74
ECDVL
Synchronous
encoder
electronic
gear -
Denominator
(lower four
digits)
Set an electronic gear denominator for converting a synchronous encoder command
into a command unit. Upper and lower are a set.
Set the electronic gear in hexadecimal.
Setting value of this parameter:
[Pr. PT74]
[Pr. PT75]
Upper four
digits
Lower four
digits
Set a value within the following range. When a value outside the range is set,
synchronous control error will occur and synchronous control will not start even
though Synchronous control command (Control DI7 bit 12) is input.
Setting "0" will apply "1".
1
16000
Synchronous encoder electronic gear - Numerator
Synchronous encoder electronic gear - Denominator
< < 6000
To enable the parameter value, cycle the power or turn on Analysis command
(Control DI 7 bit 14).
This parameter corresponds to "External encoder gear denominator (Class ID: 64h,
Ins ID: 2DF0h, Attr ID: 2)". When this parameter is mapped for the I/O
communication, the value written with Setup software (MR Configurator2
TM
) is
overwritten with the upper side. Thus, do not write a value with Setup software (MR
Configurator2
TM
).
Setting range: 00000000h to FFFFFFFFh
0000h
PT75
ECDVH
Synchronous
encoder
electronic
gear -
Denominator
(upper four
digits)
Set an electronic gear denominator for converting a synchronous encoder command
into a command unit. Upper and lower are a set.
Refer to [Pr. PT74] for details.
0000h
