8. TROUBLESHOOTING
8 - 8
No.
Name
Detail No.
Detail name
Stop
method
(Note 2, 3)
Alarm deactivation
Alarm reset
Communication
reset
Cycling the
power
Alarm
69
Command error
69.1
Forward rotation-side software limit
detection - Command excess error
SD
69.2
Reverse rotation-side software limit
detection - Command excess error
SD
69.3
Forward rotation stroke end detection -
Command excess error
SD
69.4
Reverse rotation stroke end detection -
Command excess error
SD
69.5
Upper stroke limit detection - Command
excess error
SD
69.6
Lower stroke limit detection - Command
excess error
SD
70
Load-side encoder initial
communication error 1
70.1
Load-side encoder initial communication
- Receive data error 1
DB
70.2
Load-side encoder initial communication
- Receive data error 2
DB
70.3
Load-side encoder initial communication
- Receive data error 3
DB
70.4
Load-side encoder initial communication
- Encoder malfunction (Note 6)
DB
70.5
Load-side encoder initial communication
- Transmission data error 1
DB
70.6
Load-side encoder initial communication
- Transmission data error 2
DB
70.7
Load-side encoder initial communication
- Transmission data error 3
DB
70.8
Load-side encoder initial communication
- Incompatible encoder (Note 6)
DB
70.A
Load-side encoder initial communication
- Process error 1
DB
70.B
Load-side encoder initial communication
- Process error 2
DB
70.C
Load-side encoder initial communication
- Process error 3
DB
70.D
Load-side encoder initial communication
- Process error 4
DB
70.E
Load-side encoder initial communication
- Process error 5
DB
70.F
Load-side encoder initial communication
- Process error 6
DB
71
Load-side encoder
normal communication
error 1
71.1
Load-side encoder normal
communication - Receive data error 1
EDB
71.2
Load-side encoder normal
communication - Receive data error 2
EDB
71.3
Load-side encoder normal
communication - Receive data error 3
EDB
71.5
Load-side encoder normal
communication - Transmission data
error 1
EDB
71.6
Load-side encoder normal
communication - Transmission data
error 2
EDB
71.7
Load-side encoder normal
communication - Transmission data
error 3
EDB
71.9
Load-side encoder normal
communication - Receive data error 4
EDB
71.A
Load-side encoder normal
communication - Receive data error 5
EDB
