18 - 137

18．EtherCAT COMMUNICATION

(3) Receive PDO Mapping (1602h)

Index

Sub

Name

Data Type

Access

PDO Mapping

1602h

Receive PDO Mapping

UNSIGNED8

Impossible

Mapped Object 001

UNSIGNED32

Mapped Object 032

Index

Sub

Default

Range

Units

EEP-ROM

Parameter

1602h

00h to 20h (32)

Impossible

00000000h

00000000h to FFFFFFFFh

00000000h

The details are the same as those of (1) in this section. Refer to (1) in this section.

(4) Receive PDO Mapping (1603h)

Index

Sub

Name

Data Type

Access

PDO Mapping

1603h

Receive PDO Mapping

UNSIGNED8

Impossible

Mapped Object 001

UNSIGNED32

Mapped Object 032

Index

Sub

Default

Range

Units

EEP-ROM

Parameter

1603h

00h to 20h (32)

Impossible

00000000h

00000000h to FFFFFFFFh

00000000h

The details are the same as those of (1) in this section. Refer to (1) in this section.
