18 - 139

18．EtherCAT COMMUNICATION

(7) Transmit PDO Mapping (1A02h)

Index

Sub

Name

Data Type

Access

PDO Mapping

1A02h

Transmit PDO Mapping

UNSIGNED8

Impossible

Mapped Object 001

UNSIGNED32

Mapped Object 032

Index

Sub

Default

Range

Units

EEP-ROM

Parameter

1A02h

00h to 20h (32)

Impossible

00000000h

00000000h to FFFFFFFFh

00000000h

The details are the same as those of (5) in this section. Refer to (5) in this section.

(8) Transmit PDO Mapping (1A03h)

Index

Sub

Name

Data Type

Access

PDO Mapping

1A03h

Transmit PDO Mapping

UNSIGNED8

Impossible

Mapped Object 001

UNSIGNED32

Mapped Object 032

Index

Sub

Default

Range

Units

EEP-ROM

Parameter

1A03h

00h to 20h (32)

Impossible

00000000h

00000000h to FFFFFFFFh

00000000h

The details are the same as those of (5) in this section. Refer to (5) in this section.
