18．EtherCAT COMMUNICATION
(4) Parameter Objects PD (2181h to 21B0h)
Index
Sub
Name
Data Type
Access
PDO Mapping
2181h
0
PD01
INTEGER32
rw
Impossible
21B0h
PD48
Index
Sub
Default
Range
Units
EEP-ROM
Parameter
2181h
0
Refer to "_ Driver Instruction Manual".
Possible
PD01
21B0h
PD48
The value of the I/O setting parameters ([Pr. PD_ _ ]) can be obtained and set.
(5) Parameter Objects PE (2201h to 2240h)
Index
Sub
Name
Data Type
Access
PDO Mapping
2201h
0
PE01
INTEGER32
rw
Impossible
2240h
PE64
Index
Sub
Default
Range
Units
EEP-ROM
Parameter
2201h
0
Refer to "_ Driver Instruction Manual".
Possible
PE01
2240h
PE64
The value of the extension setting 2 parameters ([Pr. PE_ _ ]) can be obtained and set.
(6) Parameter Objects PF (2281h to 22C0h)
Index
Sub
Name
Data Type
Access
PDO Mapping
2281h
0
PF01
INTEGER32
rw
Impossible
22C0h
PF64
Index
Sub
Default
Range
Units
EEP-ROM
Parameter
2281h
0
Refer to "_ Driver Instruction Manual".
Possible
PF01
22C0h
PF64
The value of the extension setting 3 parameters ([Pr. PF_ _ ]) can be obtained and set.
