18 - 149

18．EtherCAT COMMUNICATION

(4) Current alarm (2A41h)

Index

Sub

Name

Data Type

Access

PDO Mapping

2A41h

Current alarm

UNSIGNED32

Possible

Index

Sub

Default

Range

Units

EEP-ROM

Parameter

2A41h

00000000h to FFFFFFFFh

Impossible

The number of the current alarm is returned. When no alarm has occurred, "00000000h" is returned. The

description of the values is as follows. If [AL. 16.3] occurs, "00160003h" is returned.

Bit

Description

0 to 15

Alarm detail No.

16 to 31

Alarm No.

(5) Parameter error number (2A44h)

Index

Sub

Name

Data Type

Access

PDO Mapping

2A44h

Parameter error number

UNSIGNED16

Impossible

Index

Sub

Default

Range

Units

EEP-ROM

Parameter

2A44h

0000h to 01F4h (500)

Impossible

When [AL. 37 Parameter error] has occurred, the number of the parameters which cause the error is

returned. Refer to Parameter error list (2A45h) for the number of each parameter which causes the error.
