18．EtherCAT COMMUNICATION
(3) Gear ratio (6091h)
Index
Sub
Name
Data Type
Access
PDO Mapping
6091h
0
Gear ratio
UNSIGNED8
ro
Impossible
1
Motor revolutions
UNSIGNED32
rw
Possible
2
Shaft revolutions
Index
Sub
Default
Range
Units
EEP-ROM
Parameter
6091h
0
2
02h to 02h
Impossible
1
1
00000001h to 00FFFFFFh (16777215)
rev
Possible
PA06
2
PA07
Set the electronic gear. Refer to [Pr. PA06] for the settable values. In the cyclic synchronous mode ,
setting Motor revolutions (6091h: 1) or Shaft revolutions (6091h: 2) to anything other than "1" will trigger
[AL. 37].
Gear ratio (6091h) =
Motor revolutions (6091h: 1)
Shaft revolutions (6091h: 2)
(4) Feed constant (6092h)
Index
Sub
Name
Data Type
Access
PDO Mapping
6092h
0
Feed constant
UNSIGNED8
ro
Impossible
1
Feed
INTEGER32
rw
Possible
2
Shaft revolutions
Index
Sub
Default
Range
Units
EEP-ROM
Parameter
6092h
0
2
02h to 02h
1
Refer to the text.
pos units
Impossible
2
1
rev
No value can be written because Feed (6092h: 1) and Shaft revolutions (6092h: 2) are set automatically
with the control mode, [Pr. PT01] and [Pr. PT03]. Writing any value causes SDO Abort Code (0609
0030h Value range of parameter exceeded).
This object is available with drivers.
Control mode
[Pr. PT01] setting
[Pr. PT03] setting
Range
Feed
Shaft revolutions
Cyclic synchronous
mode
_ _ _ 0 to _ _ _ 3
Encoder resolution of
the servo motor
1
Profile mode
_ 0 _ _ (mm)
_ 1 _ _ (inch)
_ _ _ 0
Encoder resolution of
the servo motor
1
_ _ _ 1
10
_ _ _ 2
100
_ _ _ 3
1000
_ 2 _ _ (degree)
_ _ _ 0 to _ _ _ 3
360000
1
_ 3 _ _ (pulse)
Encoder resolution of
the servo motor
Point table method
(Note)
_ 0 _ _ (mm)
_ 1 _ _ (inch)
_ _ _ 0
Encoder resolution of
the servo motor
1
_ _ _ 1
10
_ _ _ 2
100
_ _ _ 3
1000
_ 3 _ _ (pulse)
_ _ _ 0 to _ _ _ 3
1
Indexer method (Note)
_ _ _ 0 to _ _ _ 3
[Pr. PT28] setting
1
