18．EtherCAT COMMUNICATION
Position actual value (6064h) is calculated from Gear ratio (6091h) and Feed constant (6092h), as
follows.
Position actual value (6064h) =
Position actual internal value (6063h) × Feed constant (6092h)
Position encoder resolution (608Fh) × Gear ratio (6091h)
When the unit is degree, the operation result will be limited within 0 to 359999.
(5) SI unit position (60A8h)
Index
Sub
Name
Data Type
Access
PDO Mapping
60A8h
0
SI unit position
UNSIGNED32
rw
Impossible
Index
Sub
Default
Range
Units
EEP-ROM
Parameter
60A8h
0
0
Refer to the text.
pos units
Impossible
No value can be written because SI unit position (60A8h) is set automatically with the control mode, [Pr.
PT01] and [Pr. PT03]. Writing any value causes SDO Abort Code (0609 0030h Value range of parameter
exceeded).
This object is available with drivers
Control mode
[Pr. PT01] setting
[Pr. PT03] setting
Range
Cyclic synchronous mode
_ _ _ 0 to _ _ _ 3
00000000h (1 pulse)
Profile mode
_ 0 _ _ (mm)
_ _ _ 0 (× 1)
FA010000h (0.001 mm)
_ _ _ 1 (× 10)
FB010000h (0.01 mm)
_ _ _ 2 (× 100)
FC010000h (0.1 mm)
_ _ _ 3 (× 1000)
FD010000h (1 mm)
_ 1 _ _ (inch)
_ _ _ 0 (× 1)
FCC00000h (0.0001 inch)
_ _ _ 1 (× 10)
FDC00000h (0.001 inch)
_ _ _ 2 (× 100)
FEC00000h (0.01 inch)
_ _ _ 3 (× 1000)
FFC00000h (0.1 inch)
_ 2 _ _ (degree)
_ _ _ 0 to _ _ _ 3
FD410000h (0.001 degree)
_ 3 _ _ (pulse)
00000000h (1 pulse)
Point table method
_ 0 _ _ (mm)
_ _ _ 0 (× 1)
FA010000h (0.001 mm)
_ _ _ 1 (× 10)
FB010000h (0.01 mm)
_ _ _ 2 (× 100)
FC010000h (0.1 mm)
_ _ _ 3 (× 1000)
FD010000h (1 mm)
_ 1 _ _ (inch)
_ _ _ 0 (× 1)
FCC00000h (0.0001 inch)
_ _ _ 1 (× 10)
FDC00000h (0.001 inch)
_ _ _ 2 (× 100)
FEC00000h (0.01 inch)
_ _ _ 3 (× 1000)
FFC00000h (0.1 inch)
_ 3 _ _ (pulse)
_ _ _ 0 to _ _ _ 3
00000000h (1 pulse)
Indexer method
_ _ _ 0 to _ _ _ 3
00000000h (no unit)
