19 - 111
19．EtherNet/IP COMMUNICATION
(2) Store parameters (Instance ID: 1010h) (Class ID 64h: Drive Configuration Object)
Ins ID
Attr ID
Access
Name
Data Type
1010h
0
Get
Store parameters
USINT
1
Get/Set
Save all parameters
UDINT
2
(Not
sup-port
ed)
(Note)
Save communication parameters
3
(Not
sup-port
ed)
(Note)
Save application parameters
Ins ID
Attr ID
Default
Range
Units
EEP-ROM
Parameter
1010h
0
3
03h
Impossible
1
00000001h
Refer to the following table.
2
(Not
sup-port
ed)
(Note)
3
(Not
sup-port
ed)
(Note)
Note.
This is not supported by the driver.
Writing "65766173h" (= reverse order of ASCII code of "save") to the corresponding sub object saves an
object value in EEP-ROM. The relationship between Attribute ID and the saved object is shown below.
Attr ID
Saved object
1
All objects
Whether saving a parameter has been completed can be checked by reading this object. The read
values are as follows.
bit
Description
0
0: The parameter cannot be saved with the command. (A parameter is being saved.)
1: The parameter can be saved with the command. (No parameter is being saved.)
1
0: The parameter is not automatically saved.
2 to 31
Unused
This instance supports the following services.
Service Code
Name
Description
0Eh
Get_Attribute_Single
Reads the value of the specified attribute.
10h
Set_Attribute_Single
Writes a value to the specified attribute.
