SMC Networks LECSN-T Series User Manual

19 - 153
19．EtherNet/IP COMMUNICATION
(34) Scale ABS counter (2D37h)
Ins ID
Attr ID
Access
Name
Data Type
2D37h
0
Get
Scale ABS counter
DINT
Ins ID
Attr ID
Default
Range
Units
EEP-ROM
Parameter
2D37h
0
80000000h to 7FFFFFFFh
rev
Impossible
The ABS counter of the scale measurement encoder is returned. Returned values differ depending on
the scale measurement encoder type.
Scale measurement encoder
Description
Rotary encoder
Multi-revolution ABS counter
Linear encoder
Absolute position type
Fixed to 0
Linear encoder
Incremental type
Fixed to 0
Linear encoder
A/B/Z-phase differential
output type
Incremental type
Fixed to 0
(35) Scale measurement encoder resolution (2D38h)
Ins ID
Attr ID
Access
Name
Data Type
2D38h
0
Get
Scale measurement encoder resolution
UDINT
Ins ID
Attr ID
Default
Range
Units
EEP-ROM
Parameter
2D38h
0
00000000h to FFFFFFFFh
inc / rev
Impossible
The resolution of the scale measurement encoder is returned.
(36) Scale measurement encoder reception status (2D3Ch)
Ins ID
Attr ID
Access
Name
Data Type
2D3Ch
0
Get
Scale measurement encoder reception status (Note)
UDINT
Ins ID
Attr ID
Default
Range
Units
EEP-ROM
Parameter
2D3Ch
0
00000000h to FFFFFFFFh
Impossible
The alarm data of the scale measurement encoder is returned. The value "0" indicates that no error
occurs. A value other than "0" indicates that an error occurs.
