20 - 14
20．PROFINET COMMUNICATION
Direction
IO Data
number
Name
Data
length (Bit)
Remark
Drive to Upper side
21
Touch probe pos1 pos value
32
Refer to chapter 5
and chapter 6.
Map size: 60 bytes
(Note)
22
23
Touch probe pos1 neg value
32
24
25
Touch probe pos2 pos value
32
26
27
Touch probe pos2 neg value
32
28
29
Touch probe status
16
30
Reserved
16
Note.
When changing a mapping, set the total size 60 bytes. Use Reserve (PNU = 0) to adjust mapping size. To change a data length
(Bit), set SubIndex in Reserve to 0, 8, or 16.
