20PROFINET COMMUNICATION
(2) Details of Touch probe function (P24760)
Bit
Definition
0
0: Touch probe 1 disabled
1: Touch probe 1 enabled
1
0: Single trigger mode
1: Continuous trigger mode
2
0: Set input of touch probe 1 as a trigger
1: Set 0 point of the encoder as a trigger
3
(Reserved)
4
0: Stop sampling at the rising edge of touch probe 1
1: Start sampling at the rising edge of touch probe 1
When the input of touch probe 1 is set as a trigger (Bit 2 = 0), the position feedback latched at rising edge of touch probe 1
is stored in Touch probe pos1 pos value (P24762).
When the encoder zero point is set as a trigger (Bit 2 = 1), the position feedback of when the encoder zero point was
passed through is stored in Touch probe pos1 pos value (P24762).
5
0: Stop sampling at the falling edge of touch probe 1
1: Start sampling at the falling edge of touch probe 1
When the input of touch probe 1 is set as a trigger (Bit 2 = 0), the position feedback latched at falling edge of touch probe 1
is stored in Touch probe pos1 neg value (P24763).
When the encoder zero point is set as a trigger (Bit 2 = 1), the position feedback of when the encoder zero point was
passed through is stored in Touch probe pos1 neg value (P24763).
6
(Reserved)
7
(Reserved)
8
0: Touch probe 2 disabled
1: Touch probe 2 enabled
9
0: Single trigger mode
1: Continuous trigger mode
10
0: Set input of touch probe 2 as a trigger
1: Set 0 point of the encoder as a trigger
11
(Reserved)
12
0: Stop sampling at the rising edge of touch probe 2
1: Start sampling at the rising edge of touch probe 2
When the input of touch probe 2 is set as a trigger (Bit 10 = 0), the position feedback latched at rising edge of touch probe 2
is stored in Touch probe pos2 pos value (P24764).
When the encoder zero point is set as a trigger (Bit 10 = 1), the position feedback of when the encoder zero point was
passed through is stored in Touch probe pos2 pos value (P24764).
13
0: Stop sampling at the falling edge of touch probe 2
1: Start sampling at the falling edge of touch probe 2
When the input of touch probe 2 is set as a trigger (Bit 10 = 0), the position feedback latched at falling edge of touch probe
2 is stored in Touch probe pos2 neg value (P24765).
When the encoder zero point is set as a trigger (Bit 10 = 1), the position feedback of when the encoder zero point was
passed through is stored in Touch probe pos2 neg value (P24765).
14
(Reserved)
15
(Reserved)
