20．PROFINET COMMUNICATION
(3) Details of Touch probe status (P24761)
Bit
Definition
0
0: Touch probe 1 disabled
1: Touch probe 1 enabled
1
0: The rising edge position of touch probe 1 has not been stored.
1: The rising edge position of touch probe 1 has been stored.
When the position feedback is stored in Touch probe pos1 pos value (P24762), "1" will be set.
Setting Bit 4 of Touch probe function (P24760) to "0" will clear the value to "0".
2
0: The falling edge position of touch probe 1 has not been stored.
1: The falling edge position of touch probe 1 has been stored.
When the position feedback is stored in Touch probe neg1 neg value (P24763), "1" will be set.
Setting Bit 5 of Touch probe function (P24760) to "0" will clear the value to "0".
3-7
(Reserved)
8
0: Touch probe 2 disabled
1: Touch probe 2 enabled
9
0: The rising edge position of touch probe 2 has not been stored.
1: The rising edge position of touch probe 2 has been stored.
When the position feedback is stored in Touch probe pos2 pos value (P24764), "1" will be set.
Setting Bit 12 of Touch probe function (P24760) to "0" will clear the value to "0".
10
0: The falling edge position of touch probe 2 has not been stored.
1: The falling edge position of touch probe 2 has been stored.
When the position feedback is stored in Touch probe neg2 neg value (P24765), "1" will be set.
Setting Bit 13 of Touch probe function (P24760) to "0" will clear the value to "0".
11-15
(Reserved)
