20 - 140
20．PROFINET COMMUNICATION
(52) Alarm Monitor 25 Electrical angle (P11161)
The electrical angle at alarm occurrence is returned.
PNU
Sub
Access
Name
Data Type
Description
Default
11161
0
R
Alarm Monitor 25
Electrical angle
Integer32
Electrical angle at alarm occurrence
PNU
Sub
Range
Units
EEP-ROM
Parameter
11161
0
80000000h to 7FFFFFFFh
pulse
Impossible
(53) Alarm Monitor 35 Motor-side/load-side position deviation (P11171)
The motor-side/load-side position deviation at alarm occurrence is returned.
PNU
Sub
Access
Name
Data Type
Description
Default
11171
0
R
Alarm Monitor 35
Motor-side/load-side
position deviation
Integer32
Motor-side/load-side position deviation at
alarm occurrence
PNU
Sub
Range
Units
EEP-ROM
Parameter
11171
0
80000000h to 7FFFFFFFh
pulse
Impossible
(54) Alarm Monitor 36 Motor-side/load-side speed deviation (P11172)
The servo motor-side/load-side speed deviation at alarm occurrence is returned.
PNU
Sub
Access
Name
Data Type
Description
Default
11172
0
R
Alarm Monitor 36
Motor-side/load-side
speed deviation
Integer32
Motor-side/load-side speed deviation at
alarm occurrence
PNU
Sub
Range
Units
EEP-ROM
Parameter
11172
0
80000000h to 7FFFFFFFh
r/min
Impossible
(55) Alarm Monitor 37 Internal temperature of encoder (P11173)
The internal temperature of encoder at alarm occurrence is returned.
PNU
Sub
Access
Name
Data Type
Description
Default
11173
0
R
Alarm Monitor 37
Internal temperature of
encoder
Integer32
Internal temperature of encoder at alarm
occurrence
PNU
Sub
Range
Units
EEP-ROM
Parameter
11173
0
80000000h to 7FFFFFFFh
˚C
Impossible
(56) Alarm Monitor 38 Settling time (P11174)
The settling time at alarm occurrence is returned.
PNU
Sub
Access
Name
Data Type
Description
Default
11174
0
R
Alarm Monitor 38
Settling time
Integer32
Settling time at alarm occurrence
PNU
Sub
Range
Units
EEP-ROM
Parameter
11174
0
80000000h to 7FFFFFFFh
ms
Impossible
