SMC Networks LECSN-T Series User Manual

20 - 139
20．PROFINET COMMUNICATION
(47) Alarm Monitor 17 Load-side droop pulses (P11153)
The load-side droop pulses (load-side encoder unit) at alarm occurrence are returned.
PNU
Sub
Access
Name
Data Type
Description
Default
11153
0
R
Alarm Monitor 17
Load-side droop pulses
Integer32
Load-side droop pulses (load-side encoder
unit) at alarm occurrence
PNU
Sub
Range
Units
EEP-ROM
Parameter
11153
0
80000000h to 7FFFFFFFh
pulse
Impossible
(48) Alarm Monitor 18 Load-side encoder information 1 Z-phase counter (P11153)
The load-side encoder information 1 at alarm occurrence is returned.
PNU
Sub
Access
Name
Data Type
Description
Default
11154
0
R
Alarm Monitor 18
Load-side encoder
information 1 Z-phase
counter
Integer32
Load-side encoder information 1 at alarm
occurrence
PNU
Sub
Range
Units
EEP-ROM
Parameter
11154
0
80000000h to 7FFFFFFFh
pulse
Impossible
(49) Alarm Monitor 19 Load-side encoder information 2 (P11155)
The load-side encoder information 2 at alarm occurrence is returned.
PNU
Sub
Access
Name
Data Type
Description
Default
11155
0
R
Alarm Monitor 19
Load-side encoder
information 2
Integer32
Load-side encoder information 2 at alarm
occurrence
PNU
Sub
Range
Units
EEP-ROM
Parameter
11155
0
80000000h to 7FFFFFFFh
rev
Impossible
(50) Alarm Monitor 23 Temperature of motor thermistor (P11159)
The temperature of servo motor thermistor at alarm occurrence is returned.
PNU
Sub
Access
Name
Data Type
Description
Default
11159
0
R
Alarm Monitor 23
Temperature of motor
thermistor
Integer32
Temperature of servo motor thermistor at
alarm occurrence
PNU
Sub
Range
Units
EEP-ROM
Parameter
11159
0
80000000h to 7FFFFFFFh
˚C
Impossible
(51) Alarm Monitor 24 Motor-side cumu. feedback pulses (before gear) (P11160)
The cumulative feedback pulses (servo motor-side unit) at alarm occurrence are returned.
PNU
Sub
Access
Name
Data Type
Description
Default
11160
0
R
Alarm Monitor 24
Motor-side cumu.
feedback pulses (before
gear)
Integer32
Cumulative feedback pulses (servo
motor-side unit) at alarm occurrence
PNU
Sub
Range
Units
EEP-ROM
Parameter
11160
0
80000000h to 7FFFFFFFh
pulse
Impossible
