4-38 Phaser 4500/4510 Service Manual
General Troubleshooting
6 Check the print cartridge right guide
assembly (1)
Does the Ground Plate of the print
cartridge right guide make proper contact
with terminals on the HVPS/engine logic
board?
Go to step 7. Replace the
print
cartridge
right guide
assembly
(page 8-47).
7 Check the print cartridge right guide
assembly (2):
1.Remove the print cartridge.
2.Remove the print cartridge right guide
assembly (page 8-47).
Is the Ground Plate of the print cartridge
right guide free of damage or deposits?
Go to step 8. Clean the
plate or
replace the
print
cartridge
right guide
assembly
(page 8-47).
8 Check ANT harness assembly for
continuity:
1.Disconnect P/J15 from the HVPS/engine
logic board.
Is J15 <=> J150 continuous?
Go to step 9. Replace ANT
harness
assembly.
9 Check the PWB grounds:
Remove the LVPS Shield Plate and HVPS
Shield Plate. (RRP12.1, 12.9)
Is the ground normal?
Are the screws for the grounds of the
following PWBs firmly tightened?
■ All screws of HVPS/engine logic board
■ All screws of LVPS
When an Optional 550-Sheet Paper Feeder
is installed:
Are the screws of the 550-sheet feeder
PWBA firmly tightened?
When a duplex unit is installed:
Are the screws of the duplex unit PWBA
firmly tightened?
When a stacker is installed:
Are the screws of the stacker PWBA firmly
tightened?
Go to step 10. Repair the
faulty ground.
10 Warning: Allow the fuser assembly to cool
down before removing.
Replace the fuser assembly (page 4-15).
Does the problem still occur after
replacement?
Go to step 11. Problem
solved.
11 Replace the HVPS/engine logic board
(page 8-73).
Does the problem still occur after
replacement?
Replace all
related parts.
Problem
solved.
Troubleshooting Procedure (continued)
Steps Actions and Questions Yes No

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
