Phaser 4500/4510 Service Manual 5-33
Print-Quality Troubleshooting
Fuser Configuration Defaults
8 Replace the following in order,
until the defective component is
found:
■ Fuser assembly (page 8-44)
■ HVPS/engine logic board
(page 8-73)
■ LVPS PWB (page 8-62)
Paper Type Default Fuser Temperature Setting
Plain Medium
Letterhead Medium
Transparency Low
Labels High
Colored Paper Medium
Card Stock High
Envelope High
Special Medium
Unfused Image Troubleshooting Procedure (continued)
Step Actions and Questions Yes No
To Next Page
