Xerox Phaser 4510 Service Manual

Phaser 4500/4510 Service Manual 9-13
Parts Lists
FRU Parts List 5.1 150-Sheet Paper Feeder
No. Name/Description Part Number
1 150 FEEDER ASSY (with 4-12, 14-23, 25-35, 37-44,
46-51)
P4500: 604K16683
P4510: 604K37313
2 FDR1 AS SUB 150 A4 (with 4-10, 12, 14-20, 22, 25-
28, 31-35, 40-42, 46-50)
3 CHUTE ASSY FDR 1 (Reference Only) (with 4-10,14-
20,40-42)
4 SUPPORT NUDGER
5 HOLDER LEFT
6 ACTUATOR NO PAPER
7 GEAR IDLER NUDGER
8 HOLDER RIGHT
9 SHAFT NUDGER
10 GEAR NUDGER 059K25270
11 ROLL ASSY NUDGER (part of item 97)
12 ROLL REGI RUBBER
14 COVER ACTUATOR
15 ACTUATOR A (part of registration actuator)
16 SPRING REGI SNR B
17 ACTUATOR B (part of registration actuator)
18 SPRING REGI SNR A
19 CHUTE BTM ASSY
20 BEARING NUDGER 013E22571
21 CLUTCH ASSY PH (J242) (feed clutch assembly) 121K28511
22 BEARING REGI LEFT
23 CLUTCH REGI (J243) 121K28511
25 CHUTE REGI
26 VARISTER
27 EARTH PLATE BASE
28 EARTH PLATE MID
29 COVER SENSOR
30 SENSOR REGI (J241) 930W00113
31 SPRING REGI 809E41093
32 BEARING REGI RIGHT
33 GEAR REGI 807E01290
34 ROLL REGI METAL
35 CHUTE EARTH REGI (P4500 only)

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
