Xerox Phaser 4510 Service Manual

9-14 Phaser 4500/4510 Service Manual
Parts Lists
37 HARNESS ASSY TRAY1 (J245-
J240,J241,J242,J243,J244)
38 SENSOR NO PAPER (P240) 930W00113
39 COVER HARNESS R
40 CHUTE TOP ASSY
41 SHAFT FEED
42 CLUTCH ONEWAY NUDGER 005E16951
43 CLUTCH ONEWAY FEED 005E16941
44 ROLL ASSY FEED (part of item 97)
45 SENSOR TONER ASSEMBLY (with 46-49) 130K63603
46 SENSOR TONER (J220)
47 HOLDER-D (part of item 46)
48 SPRING TONER (part of item 46)
49 SPRING (part of item 46)
50 HARNESS ASSY TONER 1 (J22-P221) 962K10313
51 GEAR REGI METAL (WHITE) 807E01280
97 Roller Kit (with 11 or 44, Qty. 3) 604K19890
98 KIT CHUTE REGI (with 25-28)
99 KIT CHUTE BTM (with 14-19)
FRU Parts List 5.1 150-Sheet Paper Feeder (continued)
No. Name/Description Part Number

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
