Xerox Phaser 4510 Service Manual

Phaser 4500/4510 Service Manual 9-19
Parts Lists
FRU Parts List 8.1 Xerographics
No.
Name/Description Part Number
1 ROS ASSY (Laser Unit) (J131,P140,P160,P170) P4500: 084K13156
P4510: 062K18170
2 HARNESS ASSY ROS (J13, J14, J16, J17-P131,
J140, P141, J160, J170)
3 SHIELD PLATE ROS
4 DUCT FRONT
5 FAN SUB (J270) 127K39391
6 GUIDE ASSY CRU L (with 7-15) P4500: 032K97111
P4510: 032K98870
7 GUIDE SL (part of item 6)
8 SPACER SS (part of item 6)
9 SPRING SL (part of item 6)
10 HOLDER I/L SW1 (part of item 6)
11 INTERLOCK S/W 24 V (J45) (part of item 6)
12 INTERLOCK S/W 5 V (part of item 6)
13 HOLDER I/L SW2 (part of item 6)
14 LEVER GUIDE (Guide Lever) (part of item 6)
15 GUIDE CRU LEFT (part of item 6)
16 COVER GUIDE CRU
17 HARNESS ASSY FUSER 110V (J4647-J46, J47) P4500: 962K08242
P4510: 962K45770
HARNESS ASSY FUSER 220V (J4647-J46, J47) P4500: 962K12942
P4510: 962K45782
18 LEVER FUSER LH 011E13362
19 LEVER FUSER RH P4500: 011E13373
P4510: 011E19070
20 FUSER ASSY 110V P4500: 604K28531
P4510: 604K37338
FUSER ASSY 220V P4500: 604K28541
P4510: 604K37358
21 BTR ASSY (transfer roller assembly) P4500: 802K49746
P4510: 802K96322
22 CHUTE TRANSFER 054K26071
23 PWBA ASSY ANT (P150) (part of item 25)
24 HARNESS ASSY ANT (J15-J150) (part of item 25)
25 GUIDE ASSY CRU R (J31) (with 23, 24) 032K97012
29 LEVER LINK 012K94352
30 LINK GEAR 3 012E10561

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
