9-26 Phaser 4500/4510 Service Manual
Parts Lists
PL11.1 Frame and Drive
No. Name/Description Part Number
1MOTOR COVER
2 MAIN MOTOR (J43) P4500: 127K36824
P4510: 127K46132
3 GEAR ASSY HOUSING (with 4) P4500: 604K16670
P4510: 604K38610
4 SPRING RELEASE (part of item 3)
5 CLAMP EDGE
6CLAMP-5 V0
7 CLAMP-10V0
8 CLAMP-EDGE
9 GEAR 9 807E02560
10 GEAR ASSY PLATE 007K87753
11 FOOT 550
12 GUIDE HARNESS R
13 CLAMP-RWSH
