Xerox Phaser 4510 Service Manual

I – 2 Phaser 4500/4510 Service Manual
E
Electrical
specifications
, 1-13
theory, 2-29
Electrical noise, troubleshooting, 4-37
Engine error history, 3-5
Engine logic board, 2-29
Engine NVRAM adjustments, 3-10
Environmental specifications, 1-13
Error code
E2-01 – E2-04
, 3-34
E2-11 – E2-14, 3-37
E3-1, E3-2, 3-40
E4-0, E4-2, E4-3, 3-43
E6-1, 3-45
E6-2, 3-47
E7-0, 3-51
E7-1 – E7-3, 3-49
E9-1, 3-52
E9-2, 3-53
PSE-1, 3-56
U1, 3-28
U2-1 – U2-4, 3-29
U4-1 – U4-5, 3-30
Error message summary, 3-21, 3-25
error messages
printer status
, A-6
Event log, 3-20
Exit gate, stacker, 2-27
Exit motor assembly, 2-27, 4-28
Exit motor PWBA, 2-29, 4-27
Exit roller, 2-27
Exit sensor, 2-21
F
Factory reset NVRAM, 3-14
Fan
diagnostic tests
, 3-10
duplex unit, 2-34
main, 2-29
sub, 2-29, 8-36
Fault history
accessing
, 3-5
engine error codes, 3-5
interpreting, 3-5
Fault reporting devices, 3-16
Faults
health and front panel LEDs
, 3-16
LED blink patterns, 3-16
soft and hard, 3-16
StartPage, 3-16
Feed clutches, 4-30
Feeder motor, 2-40
Front duct, 8-36
Functional specifications, 1-12
Fuser
causes for power shutoff
, 2-26
control, 2-23
exit sensor, 2-21
failure troubleshooting, 3-30
heat roller, 2-21
heat roller diode, 2-21
heat roller fingers, 2-21
heater assembly, 2-21
pressure roller, 2-21
problems (U4 error code), 2-25
temperature adjusting, 6-8
temperature cycling, 2-24
temperature defaults, 5-33
temperature sensors, 2-21
temperature stabilization, 2-25
theory, 2-21 to 2-26
thermostats, 2-21
troubleshooting, 4-15
warm-up, 2-24
G
Gate assembly solenoid, 4-57
Gate solenoid assembly, 2-37
Gear assembly housing, 2-28
Gear assembly plate, 2-28
Gear layout
duplex unit
, 2-34
optional 550-sheet feeder, 2-39
stacker, 2-36
General setup values, 6-11
Guide
left tray
, 4-31
H
Hard fault, 3-16
Health LED, 1-7, 1-8, 3-15
Heat roller, 2-21
Heater assembly, 2-21
Hidden service diagnostics menu, 3-7
High voltage power supply (HVPS), 2-29
HVPS/engine logic board, 4-32
I
Image density
adjusting
, 6-5
Image processor
isolation
, 4-33
Image processor board, 2-29
description, 1-7
troubleshooting, 4-34
Image quality analysis
fusing
, 5-7
line, band, or spot deletions, 5-6
registration, lead edge-to-trail edge, 5-10
resolution, 5-8

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
