Xerox Phaser 4510 Service Manual

Phaser 4500/4510 Service Manual I – 3
side-to-side registration, 5-9
skew, 5-13
skips/smears, 5-11
spots, 5-12
test print, 5-5
Inoperable control panel buttons, 4-3
Interlock
24 V
, 2-29, 4-24
5 V, 2-29, 4-25
diagnostic tests, 3-11
duplex unit switch, 2-34, 4-53
interlock switch assembly, 2-29
laser, 2-29
rear cover switch, 2-29, 4-26
schematic diagram, 2-31, 2-32
stacker rear cover switch, 2-37, 4-58
theory, 2-7
top cover switch, 2-29
Interlock switch assembly, 2-29, 4-26
troubleshooting, 4-25
J
Jam at duplex, 3-49, 3-51
Jam at exit, 3-43
Jam at rear, 3-45, 3-49
Jam at stacker, 3-47
Jam at top, 3-40
Jam at tray N, 3-34, 3-37
Jam history, 3-5
Jam, paper size, 3-56
L
Laser assembly, 2-19
laser diode assembly, 2-19
scanner, 2-19
start of scan board, 2-19
Laser control, 2-20
Laser diode (LD) assembly, 2-19
Laser interlock, 2-29
Laser power
adjusting
, 6-5
default, 6-5
Laser power adjustment, 3-10
Laser unit
failure troubleshooting
, 3-29
Laser unit assembly, 4-12
LCD/LED display error, 4-3
LED blink patterns, 3-16
Left tray guide, 4-31
Link lever, 2-28
Low paper actuator, 2-15, 2-40, 3-64, 3-66, 4-21, 4-43
Low paper sensor, 2-15, 2-40, 4-21
Low voltage power supply (LVPS), 2-29, 4-4
Lower stacker roller, 2-37
M
Macintosh printing problems, 3-19
Magnet roller, 2-18
Main fan, 2-29
Main motor, 2-28
failure troubleshooting, 3-28
Maintenance
tools
, 7-2
Maintenance kit, 6-9, 8-13, 8-16
description, 1-10
part numbers, 9-47
replace, 3-71
Maintenance, preventive, 7-2
Margins. See Registration
Media specifications
, 1-14
Memory
requirements
, 4-35
troubleshooting, 4-35
Memory requirements, 1-15
menu map, service, 3-8
Motor
diagnostic tests
, 3-10
duplex unit, 2-34, 4-50
exit, 2-27, 4-28
feeder, 2-40
stacker, 2-36, 2-37, 4-55
stacker offset, 2-37, 4-56
N
No control panel display after power is turned ON, 4-3
No paper actuator, 2-15, 2-40, 3-63, 3-65, 4-19, 4-41, 8-18,
8-27, 8-89
No paper sensor, 2-15, 2-40, 4-19
NVRAM
engine
, 3-10
PostScript, 1-6, 6-13
reset password, 3-14
O
Offset chute assembly, 2-37
Offset motor assembly, 2-37, 4-56
Offset sensor (on stacker PWBA), 4-61
Offset sensor (stacker), 2-37
Operating environment, 5-7
Option feeder
no paper sensor
, 2-40
Optional 550-sheet feeder, 4-39, 4-40
drive transmission path, 2-39
feed clutch, 4-46
feed roller, 2-40
functional components, 2-40
gear layout, 2-39
low paper actuator, 2-40
low paper sensor, 2-40, 4-43
motor, 2-40

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
