Xerox Phaser 4510 Service Manual

I – 4 Phaser 4500/4510 Service Manual
no paper actuator, 2-40
no paper sensor, 4-41
nudger roller, 2-40
paper feeder assembly, 2-40
paper size switch, 2-40, 4-45
theory, 2-39 to 2-41
turn roller, 2-40
turn roller clutch, 4-48
Optional hard drive
power source
, 2-29
Output tray full sensor, 2-27, 4-23
standard output tray, 4-23
P
Paper exit theory, 2-27
Paper feeder theory, 2-15
Paper lift theory, 2-14
Paper path
print engine
, 2-4
stacker, 2-37
Paper size control, 2-17
Paper size jam, 3-56
Paper size switch
optional 550-sheet feeder
, 2-40
Paper size switch assembly, 2-17
Paper transport
layout
, 2-5
Paper tray
theory
, 2-11
Password for PS NVRAM reset, 3-14
PCL setup values, 6-11
POST
diagnostics
, 3-15
diagnostics test descriptions, 3-17
error codes, 3-18
faults, 3-16
startup indications, 3-15
PostScript NVRAM, 6-13
PostScript setup values, 6-11
Power distribution schematic, 2-31, 2-32
Power on self test (POST), 3-15
Pressure roller, 2-21
Print an Event Log or Runtime Log, 3-20
Print cartridge
bias charge roller
, 2-18
charging and metering blade, 2-18
cleaning blade, 2-18
drum, 2-18
magnet roller, 2-18
Print defects
fusing
, 5-7
line, band, or spot deletions, 5-6
registration, lead edge-to-trail edge, 5-10
resolution, 5-8
side-to-side registration, 5-9
skew, 5-13
skip/smears, 5-11
spots, 5-12
Print engine troubleshooting, 4-11 to 4-37
Printer
status codes
, A-6
Printer configurations, 1-3
Printer controls setup values, 6-12
Printer options
theory
, 2-33 to 2-41
Printer orientation, standard, 8-2
Printer specifications, 1-11
clearances, 1-11
dimensions, 1-11
electrical, 1-13
environmental, 1-13
functional, 1-12
Printing problems
Macintosh
, 3-19
Windows, 3-19
Printing process
summary
, 2-2
Print-quality defect definitions, 5-3
PS NVRAM
factory reset
, 3-14
reset, 3-14
R
RAM DIMM fault isolation, 4-35
Rear cover switch, 2-29, 4-26
Registration
checking
, 6-5
duplex, adjusting, 6-8
simplex, adjusting, 6-7
Registration adjustments, 3-10
Registration clutch, 2-15, 4-29
Registration sensor, 2-15, 4-17
Reset
all printer default settings
, 6-13
control panel setup values, 6-12
general setup values, 6-11
PCL setup values, 6-11
PostScript NVRAM, 6-13
PostScript setup values, 6-11
printer controls setup values, 6-12
Reset PS NVRAM, 1-6
Reset to factory defaults, 6-10
Resetting connection setup, 6-10
Roller
duplex
, 2-34
exit, 2-27
feed (optional feeder), 2-40
heat, 2-21
lower stacker, 2-37
magnet, 2-18
nudger (optional feeder), 2-40
pressure, 2-21
transfer, 2-20
turn, 2-40
upper stacker, 2-37
Routine maintenance items, 1-9
Runtime log, 3-20

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
