Xerox Phaser 6128MFP Service Manual

3-8 Phaser 6128MFP Service Manual
Error Messages and Codes
FAX
Controller
Fax Codec Error
Error 033-515
Press OK Button
<JPEG Nf Error>
Color/BW Multi-value Info
Unavailable at JPEG
Reception.
page 3-142
FAX
Controller
Fax Codec Error
Error 033-516
Press OK Button
<JPEG EOI Error>
Failed to Detect EOI at JPEG
Reception.
page 3-142
FAX
Controller
Incorrect Password
Error 033-517
Press OK Button
<D-FAX Password Error>
The D-FAX password does not
match the password for Fax/
Scan Lock.
page 3-144
FAX
Controller
Fax Country is not Set
Error 033-518
Press OK Button
<Fax Country is not set
correctly.>
The Country setting value is
not set correctly.
Set the
[Country]
of the [Fax
Setting] on
the [Admin
Menu]
correctly.
FAX
Controller
Fax Function is
Disabled
Error 033-519
Press OK Button
<FAX Function is not set
correctly>
The FAX Function setting is
not set correctly.
Set the
[Fax] of the
[Function
Enable] on
the [Secure
Settings] of
the [Admin
Menu]
correctly.
FAX
Controller
Fax Codec Error
Error 033-520
Press OK Button
<JBF Error Call Back>
The incoming data error
occurred at the Call Back.
page 3-134
FAX
Controller
Fax Codec Error
Error 033-521
Press OK Button
<JBF Error Marker Abort>
The Abort Marker is detected.
page 3-134
FAX
Controller
Fax Codec Error
Error 033-522
Press OK Button
<JBF Error Marker Unknown>
Unsupported Maker detected.
page 3-134
FAX
Controller
Fax Codec Error
Error 033-523
Press OK Button
<JBF Error Marker Unknown>
Unsupported Maker detected.
page 3-134
FAX
Controller
Fax Codec Error
Error 033-524
Press OK Button
<JBF Error Marker Bad
ATMOVE>
The unsupported Adaptive
Template is executed.
page 3-134
FAX
Controller
Fax Codec Error
Error 033-525
Press OK Button
<JBF Error Marker Bad
Newline>
The unsupported Image Level
is executed.
page 3-134
Error Message Summary (continued)
System Error Message Error Type Go to

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
