Xerox Phaser 6128MFP Service Manual

Phaser 6128MFP Service Manual 3-9
Error Messages and Codes
FAX
Controller
Fax Codec Error
Error 033-526
Press OK Button
<JBF Error BHI>
The BIH information is
abnormal.
page 3-134
FAX
Controller
Fax Communication
Error
Error 033-751
Press OK Button to
retry
<Over Run>
Incoming data overrun at the
MODEM.
page 3-138
FAX
Controller
Targe t Fa x B usy
Error 033-752
Press OK Button
<During Call Busy Tone>
A busy tone was received
while calling the external
telephone in TEL/FAX mode.
page 3-139
FAX
Controller
Fax Communication
Error
Error 033-753
Press OK Button
<CJ Not Detection>
The CJ cannot be detected.
page 3-137
FAX
Controller
Fax Communication
Error
Error 033-754
Press OK Button
<V8 Error>
The V8 error occurred.
page 3-137
FAX
Controller
Fax Communication
Error
Error 033-755
Press OK Button
<Phase2 Error>
The Phase 2 (Line Probing)
error occurred.
page 3-137
FAX
Controller
Fax Communication
Error
Error 033-756
Press OK Button
<Phase3 Error>
The Phase 3 (Primary Channel
Equalizer Trimming) error
occurred.
page 3-137
FAX
Controller
Fax Communication
Error
Error 033-757
Press OK Button
<Primary Channel
Synchronization Error>
The Primary Channel re-
Synchronization error
occurred.
page 3-137
FAX
Controller
Fax Communication
Error
Error 033-758
Press OK Button
<Control Channel
Synchronization Error>
The Control Channel re-
Synchronization error
occurred.
page 3-137
FAX
Controller
Fax Communication
Error
Error 033-759
Press OK Button
<Control Channel Retrain
Error>
The Control Channel Retrain
Error occurred.
page 3-137
FAX
Controller
Fax Communication
Error
Error 033-760
Press OK Button
<Control Channel OFF Time
Out>
The Control Channel OFF time
out occurred.
page 3-137
Error Message Summary (continued)
System Error Message Error Type Go to

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
