272 Configuring the Wireless AP
End-to-End QoS Handling
Wired QoS - Ethernet Port:
 Egress: Outgoing wired packets are IEEE 802.1p tagged at the Ethernet
port for upstream traffic, thus enabling QoS at the edge of the network.
 Ingress: Incoming wired packets are assigned QoS priority based on their
SSID and 802.1p tag (if any), as shown in the table below. This table
follows the mapping recommended by IEEE802.11e.
FROM
AP QoS (Wireless)
TO
Priority Tag 802.1p (Wired)
1 (Lowest priority) 1
00
2 (Default) 5
3 (Highest priority) 6
FROM
Priority Tag
802.1p (Wired)
TO
AP QoS
(Wireless)
Typical Use
0 0 Best Effort
11 (Lowest
priority)
Background — explicitly designated as
low-priority and non-delay sensitive
21Spare
3 0 Excellent Effort
42Controlled Load
52Video
6 3 Voice - requires delay <10ms
