CALCulate Subsystem 3
N1911A/1912A P-Series Power Meters Programming Guide 181
Parameters
Example
Reset Condition
On reset, both measurements of the upper and lower windows are set to
–90.00 dBm or –90 dB (DEF).
Query
CALCulate[1]|2|3|4:LIMit:LOWer[:DATA]? [MIN|MAX]
The query returns the current setting of the lower limit or the values
associated with MIN and MAX for the specified window.
Item Description/Default Range of Values
numeric_value A numeric value for the lower test limit:
• DEF: the default is –90.00 dBm or
–90 db
• MIN: –150 dBm or –180 dB
• MAX: +230 dBm or +200 dB
–150 to +230 dBm or
–180 to +200 dB
DEF
MIN
MAX
CALC2:LIM:LOW:DATA 0.1 This command enters a lower limit for the
lower window/upper measurement
depending on the window’s units as
follows:
dBm = 0.1 dBm
W = 100 mW
dB = 0.1 dB
% = 0.1 %
