Agilent Technologies N1911A Programming Guide

3CALCulate Subsystem
190 N1911A/1912A P-Series Power Meters Programming Guide
Parameters
1
Quotes are mandatory. Either single or double quotes may be used.
2
N1912A only.
3
The mathematical operation will be performed in linear scale.
Example
Reset Condition
On reset, the Agilent N1911A upper and lower window measurements are
set to Channel A ("(SENS1)"). On the N1912A the upper window
measurements are set to Channel A ("(SENS1)") and the lower window
measurements to Channel B ("(SENS2)").
Item Description/Default Range of Values
string A single string value detailing the measurement
type:
• For the Agilent N1911A the default is
SENS1.
• For the Agilent N1912A the default is
SENS1 if the upper window is selected, or
SENS2 if the lower window is selected.
“(SENS1)”
1
“(SENS2)”
1,2
“(SENS1–SENS1)”
1,3
“(SENS2–SENS2)”
1,2,3
“(SENS1/SENS1)”
1
“(SENS2/SENS2)”
1,2
“(SENS1–SENS2)”
1,2,3
“(SENS2–SENS1)”
1,2,3
“(SENS1/SENS2)”
1,2
“(SENS2/SENS1)”
1,2
CALC2:MATH “(SENS2/SENS1)” This command sets the lower
window/upper measurement to make a
Channel B/A ratio measurement.
